Table 1
|
Project |
Unit |
Product Model | ||||
|
SD8 |
SD14 |
SD20 |
SD25 | |||
|
Volume |
m3 |
8 |
14 |
20 |
25 | |
|
Load |
t |
16 |
28 |
40 |
50 | |
|
Gauge |
mm |
600/762/900 | ||||
|
Dimensions |
Long |
mm |
9540 |
11260 |
12500 |
14500 |
| Wide | mm | 1570 |
1802 |
1960 |
1960 | |
|
High |
mm |
1900 |
2400 |
2700 |
2700 | |
|
Lap height |
m |
1.32 |
1.32 |
1.22 |
1.15 | |
|
Unloading time |
min |
1.5 |
1.5 |
2.5 |
3 | |
|
Cycling minimum turning radius |
m |
10 |
20 |
20 |
20 | |
|
Lap minimum turning radius |
m |
15 |
20 |
25 |
25 | |
|
Maximum driving speed |
km/h |
20 | ||||
|
Auxiliary electrical power |
kW |
15 |
22 |
22×2 |
22×2 | |
|
Recommended with rail |
kg/m |
≥18 |
≥18 |
≥33.43 |
≥33.43 | |
|
Applicable roadway sections (W x H) |
m2 |
≥2.5×2.5 |
≥3×3.4 |
≥3.5×3.5 |
≥3.5×3.5 | |
|
Product weight |
t |
≈14.1 |
≈19.8 |
≈26.7 |
≈30.8 | |
|
Applicable roadway slope |
° |
≤6 | ||||
